Klauke EK-50-ML UK Electromechanical crimping tool for insulated and uninsulated crimp terminals
- The Klauke micro with intuitive PowerSense function merges the benefits of manual crimping tools with the efficiency of battery powered hydraulic crimping tools
- Provides excellent crimping results with minimum effort
Hydraulic crimp tool for wire end ferules & connectors
The Klauke EK50MLUK crimp tool tool is the perfect tool to crimp insulated and uninsulated terminals and covers a wide cable range, 0.14 mm² to 50 mm². The EK 50 ML electromechanical crimping tool features a single lever trigger mechanism for all functions. The lightweight and ergonomic crimp tool with PowerSense function makes this the perfect solution for large volume crimping. The motorised mechanism supplies the correct power for accurate and consistent terminations while reducing the overstraining sometimes found with manual crimpers.
Features
- Simple and safe: One-button operating concept for controlling all tool functions
- Electronic control with locking function monitors full closing of the dies
- Automatic retraction when operation is complete
- Manual retract as required
- Motor stall protection
- Ergonomic 2C housing in the Klauke “In-line Design”
- Fastening eye for use with balancer or as fall protection in field applications
- Very low weight and high speed for maximum efficiency
- Powerful drive technology for fatigue proof operations
- Powerful 10.8 V Li-Ion battery with charge status display
- LED for work area illumination
- Maintenance display via LED
- 24 month warranty (free extension to 36 month)
- suitable for series 50 interchangeable crimping dies
Specifications
| Crimping force | 15kN |
| Crimping range | 0.14 – 50mm² |
| Crimping cycle | <1.5s (based on connection material) |
| Number of crimps | approx 300 for 10mm² Cu DIN 46234 / per battery charge |
| Battery voltage | 10.8V |
| Battery capacity | 1.5Ah, Li-Ion |
| Battery charging time | approx 40 min |
| Ambient temperature | -10°C to + 40°C |
| Weight including battery | 0.96kg |
Scope of supply
| EK50ML | Elecromechanical Crimping Tool |
| RAML1 | Li-Ion Battery 10.8V |
| LGML1 | Battery Charger 230V |
| IS50 | Crimping Dies 0.5 – 6mm2 Pre-insulated |
| KKEK50ML | Plastic Carrying Case |
Compatability
TUBULAR CABLE LUGS AND CONNECTORS – CU
| Suitable For | Connecting Material | Crimp Range mm² | Crimping Profile | Crimping Dies Available |
| Tubular cable lugs and connectors – Cu, standard design |  |
0.75 – 10 |  |
Crimping dies R 50, indent crimping |
| Tubular cable lugs and connectors – Cu, standard design | |
6 – 25 |  |
Crimping dies R 50, hexagonal crimp |
| Tubular cable lugs and compression joints for solid conductors – Cu |  |
1.5 – 10 | |
Crimping dies M 50 |
COMPRESSION CABLE LUGS AND CONNECTORS TO DIN – CU
| Suitable For | Connecting Material | Crimp Range mm² | Crimping Profile | Crimping Dies Available |
| Compression cable lugs (DIN 46235) and connectors (DIN 46237, part 1) according to DIN – Cu |  |
6 – 25 | |
Crimping dies D 50 |
SOLDERLESS TERMINALS, CONNECTORS AND PIN TERMINALS TO DIN – CU
| Suitable For | Connecting Material | Crimp Range mm² | Crimping Profile | Crimping Dies Available |
| Solderless terminals (DIN 46234), pin terminals (DIN 46230) and solderless connectors (DIN 46341) according to DIN – Cu |  |
0.5 – 10 | |
Crimping dies Q 50 |
CABLE END SLEEVES
| Suitable For | Connecting Material | Crimp Range mm² | Crimping Profile | Crimping Dies Available |
| Cable end sleeves |  |
0.14 – 50 |  |
Crimping dies AE 50 |
CABLE CONNECTIONS, INSULATED AND NON-INSULATED
| Suitable For | Connecting Material | Crimp Range mm² | Crimping Profile | Crimping Dies Available |
| Insulated cable connections, single crimping |  |
0.5 – 16 |  |
Crimping dies IS 50, simple crimping |
| Insulated cable connections, double crimping | |
0.1 – 6 | |
Crimping dies IS 50, double crimping |
| Non-insulated receptacles |  |
0.25 – 6 |  |
Crimping dies CR 50 |
| For stud and shielded sleeves, BNC plugs for coax cable RG 58, 59, 62 and 71 | – | – | Crimping dies BNC 50 | |
| Turned pin receptacle, pin connectors | – | 0.1 – 4 |  |
Crimping dies SB 50 |
